IM-55 5 SEC ACCUARACY
Product Introduction
The Sokkia IM-55 Total Station is a precision surveying instrument designed for a variety of applications, including construction layout, topographic surveys, and engineering projects. Part of Sokkia’s iM series, the IM-55 model combines advanced technology with ease of use, offering reliability and accuracy for professional surveyors. Here’s a detailed description of the Sokkia IM-55 Total Station.
Features:
5″ Accuracy, Fast distance measurement of 0.9s..
Reflectorless operation from 30cm to 500m.
50,000-point internal memory
Upto 32GB USB Pen Drive Support
Coaxial EDM beam and laser-ponter provide fast and accurate aiming.
Ensures accuracy even with reflective sheets.
IP66 dust-proof waterproof rating.
Rugged metal chassis and heavy duty handle.
Standard usage temperature range -20° to 60°C.
IM-52 2 SEC ACCUARACY
Product Introduction
The SokkiaIM 52 Total Station offers superior performance and reliability, thanks to its cutting-edge technology and robust design. It features a high-accuracy EDM that allows you to measure distances with an accuracy of up to ±(2mm + 2ppm). The dual-axis compensation feature ensures that you get accurate results, even when the instrument is not perfectly level.
Features:
2″ Accuracy, Fast distance measurement of 0.9s.
Dual-side Alphanumeric Keyboard Display.
Reflectorless operation from 30cm to 500m.
50,000-point internal memory
Upto 32GB USB Pen Drive Support
Coaxial EDM beam and laser-ponter provide fast and accurate aiming.
Ensures accuracy even with reflective sheets.
IP66 dust-proof waterproof rating.
Rugged metal chassis and heavy duty handle.
IM-101 1 SEC ACCUARACY
Product Introduction
The iM-101 1″ Second Accuracy Total Station is a versatile and cost-effective solution for demanding surveying tasks, whether for layout or as-built projects. Designed for challenging environments, the dual-axis compensation ensures stable and precise measurements by automatically correcting vertical and horizontal angles. Additional features such as a built-in laser plummet, 50,000 points of internal memory, support for a 32GB USB flash drive, and an impressive battery life of up to 28 hours, make the iM-101 an exceptional choice for professionals seeking reliability and performance in the field.
Features:
1″ Accuracy
Fast distance measurement of 0.9s.
RED-tech technology reflectorless EDM
Reflectorless operation from 30cm to 500m.
Long-range Bluetooth technology.
Advanced angle measurement system.
The longest battery life – 36 hours.
Waterproof, rugged and operator friendly.
IM-102 2 SEC ACCUARACY
Product Introduction
The Sokkia IM 105 Total Station is a powerful surveying instrument that uses advanced technology to deliver precise and reliable results. It features auto-pointing technology that quickly and accurately locates and tracks prisms, making it easy to survey even difficult targets. The dual-axis compensation feature ensures that you get accurate measurements, even when the instrument is not perfectly level. The Sokkia IM 105 Total Station is perfect for construction, engineering, and land surveying applications where accuracy and efficiency are critical.
Features:
5″ Accuracy
Construction and Survey Application Software On Board
Best-in-Class Measuring Distance Feature
Dual Side Display Control Panel.
Reflectorless operation from 0.3m to 1000m.
Integrated Bluetooth® technology
Up to 28 hours of battery life in Eco mode.
Internal memory has 50,000 points to record.
B20 Sokkia Auto Level
B30 A Sokkia Auto Level
B40 A Sokkia Auto Level
Magnification:32x Clear
Working Range:±15’M
Temperature:-20°C to +50°C
Accuracy:0.3 MM
Minimum Focus:0.2M – 0.3M
Magnification:28x Clear
Working Range:±15’M
Temperature:-20°C to +50°C
Accuracy:0.5 MM
Minimum Focus:0.2M – 0.3M
Magnification:24x Clear
Working Range:±15’M
Temperature:-20°C to +50°C
Accuracy:0.5 MM
Minimum Focus:0.2M – 0.3M
